    200m Depth Hydraulic Core Drilling Rig Machine Fast Speed HZ-200YY

    HZ-200YY hydraulic core drilling rig


    1.Applications of HZ-200YY hydraulic core drilling rig


    HZ-200YY hydraulic core drilling rig is mainly used for geological general investigation and exploration, road and tall building foundation exploration, holes in concrete structure, river levees, civil water wells and ground temperature central air-conditioner.


    2. Features of HZ-200YY hydraulic core drilling rig


    the highest speed can reach 1045r/min with 5 gears, which improves drilling efficiency

    adopted 53*59 drilling rod, which has high rigidity and strong delivery torque.

    equipped with taper clutch, made the machine easy to operate and free of maintenance.

    using large module planetary gear and adding supporting frame, which highly increased hoisting and braking ability of the winch.

    vertical spindle are fixed by four groups of bearings to ensure that the core drilling rig is rigid enough for gravel layer and other complex geological conditions.


    3. Technical parameters of HZ-200YY hydraulic core drilling rig


    Max open hole diameter300mm
    End hole diameter75mm
    Drill rod diameter60mm
    Drilling angle90
    Drill weight (without power)975kg
    Triangle conveyer beltB950 * 4; B1700 * 3
    Main drilling rig moving distance300mm
    PowerDiesel engine 22HP
    Electric motor 15kw
    Spindle
    Spindle speed64/128/287/557r/min
    Spindle stroke450mm
    Hoist
    Max. lifting capacity2400kg
    Single line lifting speed0.41/0.82/1.64 m/s
    Wire rope diameter13mm
    Wire rope length35m
    Reel diameter140mm
    Hug floodgate diameter260mm
    Hug floodgate belt width70mm
    Mud pump
    TypeHorizontal single-urn twin-action
    DisplacementDiesel engine 170L/min
    Electric motor 150L/min
    Maximum pressure3mpa
    Work pressure1.5mpa
    Inlet pipe diameter40mm
    Outlet pipe diameter30mm
    Triangle conveyer beltB1728mm
